The WS-451 EE is the all-electric version of the WS-451 series. The blade is powered by a high-frequency electric motor and the feed motors are also electric. All working functions are operated by the universal radio frequency control in conjunction with a remote control. The controller of the WS-451 EE has an anti-lock function that automatically adjusts the feed speed when the blade speed drops. As standard, the saw has a quick-change system that can be locked from the back for the blade mounting, which is also ideal for flush cuts with the wall.
WS-451 EE
Features & Characteristics
- All-electric version
- Blade drive: Electric via high-frequency motor
- Feed motors: electric
- Operation via HF-18 high-frequency control in conjunction with a remote control
- Quick-change blade flange
- Standard with a quick-change system that can be locked from the back for leaf mounting, also for flush cuts with the wall
Components
- Sägekörper WS-451
- HFM-18 High Frequency Blade Drive Motor with 10m Connection Cable
- HF-28 High Frequency Control
- Connection cable 10 m from the HF-28 to the feed motors
- Wired Universal Control Bottle
Technical specifications
Max. cutting depth:
530 mm
max. Saw Blade Ø:
1200 mm
min. Saw Blade Ø:
600 mm
Cutting shaft speed:
variable
Bore hole of blade:
60 mm
Motor output (net):
20 kW
Motor type:
electric
Electrical connection:
400V / 32 A / 50 Hz
Cutting depth adjustment:
electric
Feed:
electric
Weight:
52 kg
